Vertical Knee-type Milling Machine

With strong support from SJR Machinery, Toptech Smac now is able to offer both metal cutting and metal forming machines to our valued customers. The produce lines include lathes, milling machines, grinding machines, power presses and hydraulic press brakes, CNC machines. With timely service and on-site training, our qualified technicians can ensure the machines’ maximum productivity. Toptech Smac also provides industrial solutions for your individual needs.

Category :

Milling Machine

Keywords: machine tool 丨 grinding machine 丨 CNC

CONTACT

MESSAGE

Product Detail

Unit	13109	13110	13111	13112	13112-1
Model		VM40	VM53K	VM42 VM42A	VM42A/1	VM42/2
Table size	mm	400 x 1600	400 x 1600	420 x 1800	420 x 2500	500x2000/2500
Longitudinal travel (Manual/Power) X	mm	900/880	980/880	1200/1180	1600	1250/1600
Cross travel (Manual/Power) Y	mm	315/300	315/300	360/350	410/400	400
Vertical travel (Manual/Power) Z	mm	385/365	385/365	460/450	460/450	400
Feed speed steps		18	18	18	15	15
Rapid feed ranges: Longitudinal X	mm/min	19-950	19-950	22.5-1180	10-1250	10-1250
Cross Y	mm/min	12.6-634	12.6-634	22.5-1180	10-1250	10-1250
Vertical Z	mm/min	6.3-317	6.3-317	8.6-420	2.5-315	2.5-315
Min. distance from spindle end to table	mm	30-500	-	60-520	340-790	0-500
Quill travel	mm	85	-	85	90	--
Spindle speed steps		18	18	18	20	20
Spindle speed ranges	rpm	30-1500	30-1500	30-1500	18-1400	18-1400
Main motor power	kg	11	11	11	11	11
Overall size	cm	255 x 215 x 219	255 x 215 x 219	243 x 226 x 243	265 x 220 x 276	277/327x253x248
Net weight	kg	4250	4250	5000	5400	5160/5400
Old model		X5040	X53K/1	X5042 X5042A	X5042A/1
